Pressure Swing Adsorption PSA Nitrogen Generator Low Power Consumption

Product Details:

Place of Origin:	Suzhou
Brand Name:	SINCE GAS
Certification:	CE,ASME,DNV,CCS,BV,ABS,LR
Model Number:	PN-200-39

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiated
Packaging Details:	Normal exporting size
Delivery Time:	within 2-3 months
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	80 sets per year

Contact Now

Detailed Product Description

Name:	PSA Nitrogen Generator	Working Pressure:	6-7 Bar
Advantage:	Low Power Consumption	Purity:	99.9-99.99%
Technology:	Pressure Swing Adsorption
High Light:	sa nitrogen plant , psa nitrogen generation system , PSA Nitrogen Generator Low Power Consumption

Pressure Swing Adsorption PSA Nitrogen Generator Low Power Consumption

PSA Nitrogen Generator Introduction

PSA Nitrogen Generator uses pressure swing adsorption principles at normal temperatures, along with clean, compressed air as the raw material, and a carbon molecular sieve as the adsorbent, the adsorbent we use from Japan & German guarantee the working life over 20 years,
Due to oxygen and nitrogen different sieves, CMS under pressure adsorbing the oxygen pass through nitrogen, by pneumatic valve control PLC system to get required nitrogen purity .

Benefits of our PSA Nitrogen Generators:

· German Technology - We have German collaboration for our technology and have fine tuned this technology to gain proprietary advantages in several key areas.
· Automated Operation - PSA Nitrogen Gas plants we manufacture incorporate complete automation and no personnel are required for operating the Gas plant.
· Low Power Consumption - We guarantee a very low power consumption for Nitrogen production by optimum design to efficiently use the compressed air and maximize production of Nitrogen gas.

PSA Nitrogen Generator Details

(1) What is PSA Technology?
PSA Technology is a very mature technology and has been around since the 1970's. In fact, thousands of PSA plants are serving customers worldwide. We have supplied our PSA plants to customers in over 56 countries.
We explain the PSA technology below using a simple process diagram.
Pressure Swing Adsorption PSA Nitrogen Generator Low Power Consumption 0
Air is composed of 78% Nitrogen and 21% Oxygen. PSA Nitrogen generation technology works on the principle of air separation by adsorbing Oxygen and separating Nitrogen.
Pressure Swing Adsorption (PSA Nitrogen) process comprises of 2 vessels filled with Carbon Molecular Sieves (CMS). (see image below for detail of vessels).
Step 1: Adsorption
Pre-filtered compressed air is passed through one CMS filled vessel. Oxygen is adsorbed by the CMS and Nitrogen comes out as the product gas. After some time of operation, the CMS inside this vessel gets saturated with Oxygen and can no longer adsorb.
Step 2: Desorption
Upon saturation of the CMS in the vessel, the process switches nitrogen generation to the other vessel, while allowing the saturated bed start the process of desorption and regeneration. The waste gas (oxygen, carbon dioxide, etc.) is discharged into atmosphere.
Step 3: Regeneration
In order to regenerate the CMS in the vessel, part of the Nitrogen produced by the other tower is purged into this tower. This allows for quick regeneration of the CMS and to make it available for production in the next cycle.
The cyclical nature of the process between the two vessels ensures continuous production of pure Nitrogen.
Pressure Swing Adsorption PSA Nitrogen Generator Low Power Consumption 1

PSA Nitrogen Generator Specifications :

Model	Capacity(Nm3/h)	Purity	Power(KW)	Overall size(mm)
PN-3-39 PN-5-29 PN-5-295 PN-8-295	3 5 5 8	99.9% 99.5% 99% 95%	0.5	180014001500
PN-5-49 PN-8-39 PN-12-295 PN-15-29	5 8 12 15	99.99% 99.9% 99.5% 99%	0.5	180014001800
PN-30-49 PN-45-39 PN-75-295 PN-88-29	30 45 75 88	99.99% 99.9% 99.5% 99%	0.5	240019002200
PN-40-49 PN-60-39 PN-100-295 PN-120-29	40 60 100 120	99.99% 99.9% 99.5% 99%	0.5	250021002500
PN-50-49 PN-70-39 PN-120-295 PN-140-29	50 70 120 140	99.99% 99.9% 99.5% 99%	0.5	260022002850
PN-60-49 PN-90-39 PN-160-295 PN-190-29	60 90 160 190	99.99% 99.9% 99.5% 99%	0.5	280022002500
PN-80-49	80	99.99%	0.5
PN-120-39 PN-200-295 PN-250-29	120 200 250	99.9% 99.5% 99%	0.5	320014002800
PN-100-49 PN-140-39 PN-250-295 PN-290-29	100 140 250 290	99.99% 99.9% 99.5% 99%	0.5	350015002800
...	...	...	...	...
Note:More news please free to contact Since Gas System Co.,Ltd or send email to us directly
