Nitrogen Generation Unit PSA Nitrogen Generator High Purity 99.9995%

Nitrogen Generation Unit PSA Nitrogen Generator High Purity 99.9995%

  • Nitrogen Generation Unit PSA Nitrogen Generator High Purity 99.9995%
Nitrogen Generation Unit PSA Nitrogen Generator High Purity 99.9995%
Product Details:
Place of Origin: Suzhou, China
Brand Name: SINCE
Certification: CE,ABS,CCS,BV,DNV,ASME,GOST,
Model Number: PN
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Exported wooden case
Delivery Time: 2 months after received down payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 sets /per year
Contact Now
Detailed Product Description
Material: Carbon Steel/Stainless Steel Certificates: BV,,CCS,ISO,TS
Capaicty: 5-5000 Nm3/h Purity: 95%-99.9995%
Dew Point: -70 ℃ Operate Power: 1 KW
Application: Fire Industry
High Light:

sa nitrogen plant

,

psa nitrogen gas generator



Nitrogen Generation Unit PSA Nitrogen Generator High Purity 99.9995%





1. PSA nitrogen generator for fire works Industry:

The Whole Nitrogen Generation System Includes :

Air Compressor

Air Dryer & Precision Filters

Air tank

Nitrogen Generator

Gas buffer tank

Nitrogen storage vessel



2. Nitrogen Generator Introduction:



The Nitrogen Generator is based on PSA (Pressure Swing Adsorption) Technology, which uses some specific molecular sieves (CMS) to separate the nitrogen gas from the air. It is more and more popular used for on-site nitrogen supply and filling nitrogen cylinders.



Our PSA Nitrogen Generator consists of air compressor, air dryer, air filters, PSA nitrogen generator and related control system. The patented vessel design enable our PSA Nitrogen Generator a lowest energy consumption and best efficiency.



Nitrogen Generator specifications:



1. Nitrogen capacity: 2~1000Nm3/h

2. Nitrogen purity: 90%, 99%, 99.5%, 99.9%, 99.99%, 99.999%...

3. Nitrogen pressure from the Nitrogen Generator: 1-7bar

4. Skid-mounted enable an easy installation and transportation.



Features of our Nitrogen Generator:



(1) The Nitrogen Generator is equipped with a stable Atlas Copco screw air compressor;

(2) The Nitrogen Generator is equipped with Siemens PLC and SMC or CKD valves;

(3) Fewer moving parts enable the Nitrogen Generator more reliable and less maintenance jobs;

(4) The NitrogenGenerator does not need foundation base;

(5) The Nitrogen Generator does not need cooling water;

(6) The Nitrogen Generator is skid-mounted, very easy to be transported and installed;

(7) The Nitrogen Generator is very easy to be operated, unmanned operation can be realized;

(8) Consumable parts: only filter elements, replaced every 6000-8000hours.

Maintenance cost is very low.





Specifications:



No

Model

Capacity(Nm3/h)

Purity

Power(KW)

Overall size(mm)

1

2

3

4

PN-3-39

PN-5-29

PN-5-295

PN-8-295

3

5

5

8

99.9%

99.5%

99%

95%





0.5





1800*1400*1500

5

6

7

8

PN-5-49

PN-8-39

PN-12-295

PN-15-29

5

8

12

15

99.99%

99.9%

99.5%

99%





0.5





1800*1400*1800

9

10

11

12

PN-10-49

PN-15-39

PN-25-295

PN-30-39

10

15

25

30

99.99%

99.9%

99.5%

99%





0.5





2000*1700*2250

13

14

15

16

PN-15-49

PN-22-39

PN-35-295

PN-45-29

15

22

35

45

99.99%

99.9%

99.5%

99%

0.5

2100*1800*2200

17

18

19

20

PN-20-49

PN-30-39

PN-50-295

PN-60-29

20

30

50

60

99.99%

99.9%

99.5%

99%

0.5

2200*1800*2200

21

22

23

24

PN-30-49

PN-45-39

PN-75-295

PN-88-29

30

45

75

88

99.99%

99.9%

99.5%

99%

0.5

2400*1900*2200

25

26

27

28

PN-40-49

PN-60-39

PN-100-295

PN-120-29

40

60

100

120

99.99%

99.9%

99.5%

99%

0.5

2500*2100*2500

29

30

31

32

PN-50-49

PN-70-39

PN-120-295

PN-140-29

50

70

120

140

99.99%

99.9%

99.5%

99%





0.5





2600*2200*2850

33

34

35

36

PN-60-49

PN-90-39

PN-160-295

PN-190-29

60

90

160

190

99.99%

99.9%

99.5%

99%





0.5





2800*2200*2500

37

PN-80-49

80

99.99%

0.5



38

39

40

PN-120-39

PN-200-295

PN-250-29

120

200

250

99.9%

99.5%

99%



0.5



3200*1400*2800

41

42

43

44

PN-100-49

PN-140-39

PN-250-295

PN-290-29

100

140

250

290

99.99%

99.9%

99.5%

99%





0.5





3500*1500*2800

...

...

...

...

...

...

Note:More news please free to contact Since Gas System Co.,Ltd or send email to us directly
