Place of Origin: | China |
Brand Name: | YUNSHENG |
Certification: | CE, GB |
Model Number: | DZ |
Minimum Order Quantity: | According to actual project |
---|---|
Price: | according to actual project, generally 20-30% cost savings over conventional materials |
Packaging Details: | Packaging suitable for export transportation |
Delivery Time: | 45days after payment |
Supply Ability: | 200000tons/year |
Pipe Diameter: | 150-1600mm | Technique: | Hot Rolled |
---|---|---|---|
Life: | 100years | Application: | Chemic Pipe |
Surface Treatment: | No Special Surface Treatment To Be Required | Standard: | GB |
Special Use: | Nuclear Power, Petrochemical Industry, Natural Gas, Seawater Desalination, Ships | Thickness: | 5-30mm |
Trade Term: | EXW,FOB | ||
High Light: | Double Sided Stainless Steel Composite Material,Hot Rolled Stainless Steel Composite Material,1600mm Stainless Steel Composite Material |
Double-Sides Stainless Steel Composite Material For Chemical Steel Pipe
Application Area:
Nuclear power, petrochemical industry, natural gas, seawater desalination, ships
Product Introduction:
The double-sided stainless steel clad steel pipe is made of double-sided stainless steel clad steel plates. Double sided stainless steel clad steel plate is hot-rolled with carbon steel as the intermediate base layer and stainless steel as the inner and outer cladding layer through a special composite process.
The main products include water transmission pipelines (inner and outer cladding of 304 stainless steel) and chemical pipelines (inner and outer cladding of 316L and 2205 stainless steel). The pipe diameter is 150-1600mm, and the pipe wall thickness varies from 5-30mm. The variety and thickness of the inner and outer stainless steel cladding of composite steel pipes can be customized according to customer needs.
Double sided stainless steel composite pipe has high mechanical strength, strong resistance to extrusion and co shock, dual purpose cold and hot, corrosion resistance, and no pollution. Due to its advantages such as almost no maintenance during use and a service life of up to 100 years, it is increasingly widely used around the world and can be widely used in water supply, river crossing water supply, nuclear power plants, thermal power plants, chemical enterprises, oil and gas transmission, etc.
Advantage:
1. Excellent corrosion resistance
The inner and outer walls of the pipe body are covered with 304 stainless steel, 316L stainless steel, duplex stainless steel, etc., which are rust
free and corrosion resistant. During use, there is no need for internal and external rust removal and anti-corrosion operations, and the service
life is long.
2. Excellent mechanical strength
Double sided stainless steel composite plate made by hot rolling. The yield strength and tensile strength of the new composite plate are
superior to those of the substrate, realizing the superposition of properties.
Base Material | Yield Strength | Tensile Strength | A/% Elongation | Coefficient Of Expansion | Thermal Conductivity W・(m・°C)-1 |
Rp0.2/MPa | Rm/MPa | (20°C) | |||
304 Stainless Steel | >205 | >520 | >40 | 1.68*10-5 | 16.3 |
Q355B | >355 | 490-670 | >21 | 1.20*10-5 | 48 |
Composite Plate | 573 | 690 | 23 | 1.33*10-5 | 21 |
3. Good hygienic performance
The food grade stainless steel coating is adopted, and the sanitary indicators meet the national standard for drinking water transmission
and distribution.
4. Washable
Pipeline robots can be regularly used for cleaning.
5. Strong adaptability
High temperature resistance, suitable for both hot and cold fluids
6. Low fluid resistance
Smooth surface, low frictional resistance, no water accumulation and scaling, fast flow rate, and low water loss
7. Low comprehensive cost
Conveying the same flow rate, the caliber can be reduced; With the same caliber and thin wall, it can reduce weight; The standard pipe length
is 12 meters, which can reduce interface welding and installation costs; Long service life and extremely low maintenance costs.
Product Specification for Large Diameter Double Sided Stainless Steel Composite Pipe (for Water Supply Pipe)
No. | Nominal Diameter (mm) | External Diameter (mm) | Thickness (mm) | No. | Nominal Diameter (mm) | External Diameter (mm) | Thickness (mm) | |
1 | DN150 | DN159 | 5 | 15 | DN700 | DN720 | 5 | |
2 | DN200 | DN219 | 5 | 16 | DN700 | DN720 | 6 | |
3 | DN300 | DN325 | 5 | 17 | DN700 | DN720 | 7 | |
4 | DN300 | DN325 | 6 | 18 | DN800 | DN820 | 6 | |
5 | DN300 | DN325 | 7 | 19 | DN800 | DN820 | 8 | |
6 | DN400 | DN426 | 5 | 20 | DN900 | DN920 | 7 | |
7 | DN400 | DN426 | 6 | 21 | DN900 | DN920 | 8 | |
8 | DN400 | DN426 | 7 | 22 | DN1000 | DN1020 | 8 | |
9 | DN500 | DN530 | 5 | 23 | DN1000 | DN1020 | 10 | |
10 | DN500 | DN530 | 6 | 24 | DN1100 | DN1120 | 8 | |
11 | DN500 | DN530 | 7 | 25 | DN1100 | DN1120 | 10 | |
12 | DN600 | DN630 | 5 | 26 | DN1200 | DN1220 | 8 | |
13 | DN600 | DN630 | 6 | 27 | DN1200 | DN1220 | 11 | |
14 | DN600 | DN630 | 7 |
