Name: Portable PSA Nitrogen Generator 20 Nm3/hr 99.99% Purity CE ASME Certified
Brand: JoShining Energy & Technology Co.,Ltd
SKU: PN-20-49
Price: 5.00 USD
Availability: InStock

Home > products > PSA Nitrogen Generator >

Portable PSA Nitrogen Generator 20 Nm3/hr 99.99% Purity CE ASME Certified

psa nitrogen generation system

psa nitrogen gas generator

SMT PSA Nitrogen Generator

Place of Origin:

Suzhou ,China

Brand Name:

SINCE-GAS

Certification:

CE,ASME, GB,CCS,ABS,LR ,

Model Number:

PN-20-49

Request A Quote

Portable PSA Nitrogen Generator 20 Nm3/hr 99.99% Purity CE ASME Certified

Product Details

Color:

White Or Customized

Material:

Mild Steel

Design Code:

CE, ASME , GB

Flow:

20 Nm3/hr

Purity:

99.99%

Characteristic:

Portable/movable

Control System:

PLC, Touch Screen

Instrument:

Pressure Gauges, Flow Meter, Oxygen Analyzer Etc

Buffer Tank:

With Pressure Safety Valve

Technology:

PSA

CMS:

Japan

Valve:

Pneumatic Valve, Ball Valve, Butterfly Valve, Control Valve

Pipeline:

Seamless Steel

PLC:

Siemens

Highlight:

psa nitrogen generation system

psa nitrogen gas generator

SMT PSA Nitrogen Generator

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiable

Packaging Details

Exporting case

Delivery Time

within 60 days

Payment Terms

L/C,T/T,Western Union,MoneyGram

Supply Ability

80 sets

BV,,CCS,TS,ISO Oil&Gas nitrogen generator package system

Get Best Price

/CCS/BV/ISO/TS Oil refinery nitrogen generator system package

Get Best Price

BV,,CCS,ISO,TS Heat treatment nitrogen generator package system

Get Best Price

BV CCS ISO TS Electron Psa Nitrogen Gas Generator Package System

Get Best Price

Contact Now

Product Description

SINCE GAS Portable Nitrogen Generator (CE/ASME Certified) for SMT & Electronics Industry

Product Attributes

Attribute	Value
Color	White or customized
Material	Mild steel
Design code	CE, ASME, GB
Flow	20 Nm3/hr
Purity	99.99%
Characteristic	Portable/movable
Control system	PLC, Touch screen
Instrument	Pressure gauges, flow meter, oxygen analyzer etc
Buffer tank	With pressure safety valve
Technology	PSA
CMS	Japan
Valve	Pneumatic valve, ball valve, butterfly valve, control valve
Pipeline	Seamless steel
PLC	Siemens

Product Description

The SINCE GAS portable nitrogen generator is CE/ASME certified for SMT and electronics industry applications, offering reliable on-site nitrogen generation.

Nitrogen Generator Features

High purity output
Excellent energy efficiency
Smooth operation with long service life
Automatic operation
ISO9001:2008 certified

PSA Nitrogen Generation Principle

The pressure swing adsorption (PSA) technology employs air separation at ambient temperatures using carbon molecular sieve (CMS) material that adsorbs oxygen to leave a rich stream of nitrogen.

Technical Features

Principle: Compressed air passes through carbon molecular sieve (CMS) using pressure swing adsorption technology
N2 flow range: 5-5000 Nm3/h
O2 purity options: 1% to 10 ppm
On-line monitoring instruments
Digital hours counter with audible/visual maintenance indicators
Economy mode option: Controls compressor shutdown/startup when nitrogen not required

Specifications

No	Model	Nm3/h	Purity	Power (KW)	Overall size (mm)
1	PN-3-39	3	99.9%	0.5	1800×1400×1500
2	PN-5-29	5	99.5%	0.5	1800×1400×1500
3	PN-5-295	5	99%	0.5	1800×1400×1500
4	PN-8-295	8	95%	0.5	1800×1400×1500
5	PN-5-49	5	99.99%	0.5	1800×1400×1800
6	PN-8-39	8	99.9%	0.5	1800×1400×1800
7	PN-12-295	12	99.5%	0.5	1800×1400×1800
8	PN-15-29	15	99%	0.5	1800×1400×1800

Note: For complete specifications or additional models, please contact SINCE GAS System Co., Ltd or email us directly.

Why Choose SINCE GAS Nitrogen Generators?

Cost Savings

Generate nitrogen on-site to significantly reduce costs with payback in just a few months. Savings include:

Elimination of transportation costs
No bulk liquid evaporation loss
No rental fees
Reduced handling and purchasing costs

Convenience

Produce nitrogen on-demand for your production line, eliminating transportation delays that could interrupt operations.
