Industrial Oxygen Plant / Medical Oxygen Generating Systems 2~150 Nm3/H

Industrial Oxygen Plant / Medical Oxygen Generating Systems 2~150 Nm3/H

  • Industrial Oxygen Plant / Medical Oxygen Generating Systems 2~150 Nm3/H
Industrial Oxygen Plant / Medical Oxygen Generating Systems 2~150 Nm3/H
Product Details:
Place of Origin: Suzhou,China
Brand Name: SINCE-GAS
Certification: CE,ABS,CCS,BV,DNV,ASME,GOST,
Model Number: PO
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Normal exported wooden case
Delivery Time: 2 months after received down payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 sets/year
Contact Now
Detailed Product Description
Capacity: 5-1500 Nm3/h Purity: 90%-94%
Dew Point: -65℃ Operate Power: 1 KW
Operation: Fully Automatic Life Span: 8-10 Years
Consumption: Energy-saving Material: Carbon Steel/stainless Steel
High Light:

Medical Grade Oxygen Generator

,

Hospital Oxygen Generator

,

150 Nm3/h Industrial Oxygen Plant



Industrial Oxygen Plant / Medical Oxygen Generating Systems 2~150 Nm3/h





PSA oxygen generator



PSA ( Pressure Swing Adsorption) Technology a revolution in Non Cryogenic Air Separation and

Oxygen Generation Technology uses special grade of ZMS ( Zeolite Molecular Sieve).

The compressed air is passed through a Twin Tower PSA module interconnected with automatic

changeover valves. After passing through a Refrigerated Dryer air gets dried. Dried compressed air

will now come in contact with bed of Zeolite molecular sieves (ZMS). Zeolite Molecular Sieves are special

grade of adsorbent which have the property of preferential adsorption of nitrogen molecules.

At a time one tower remains under nitrogen production cycle, whereas the other tower undergoes

regeneration

which is achieved through depressurization of the tower to atmospheric pressure. The outgoing oxygen

gas is sent to a surge vessel where the minimum pressure will be maintained with the help of Back

pressure Regulator



Technical Specifications:



Capacity: 2~150 Nm3/h

Purity: 92±2%

Initial Pressure: 0.05~0.4 Mpa

Dew point: -65℃

Industrial Oxygen Plant / Medical Oxygen Generating Systems 2~150 Nm3/H 0



Product Features

·

1, Full set of equipment can run in time of request or have a sudden stop. Short starting time with high

reliability.
2, Easy maintenance, less spare parts
3, Very simple operation, well-equipped monitors help to good running in state of neglect.
4, Advanced PLC control and data acquisition system, a data interface is kept for RMON
5, Scientific designation in structures, special gas diffusion unit, avoiding the high-speed impact by air flow

and CMS being broken
6, Using the automatic internal balancing & clamping device, the unique sub-filling molecular sieve technology

 help to raise reliability in long term.
7, oxygen emptying and interlock device ensure the quality level of oxygen.
8, Less occupation in land, easy installation, poor requirement in workshop, no request in foundation.



Application :

Food and beverage industries

Aircraft& motor vehicle tires

Chemical and petrochemical industries

Electronics industry

Metallurgy / heat treatment

Pharmaceutical industry

Glass and lighting industry

Oil & Gas



Why they always choose SINCE?

Many years of experience and expertise in manufacturing and supplying gas plants;

,CCS,TS certified company for quality gas plants and best after -sale services; SINCE is the seldom

company who got ,TS (Manufacture License of special equipment)

CCS(CHINA CLASSIFICATION SOCIETY) certificate,SINCE also can manufacture marine nitrogen

generator.

Excellent infrastructure set up teamed by experienced and qualified engineers.

Sophisticated and developed R&D wing in assistance for installation and use of plants.
