Stainless Steel Composite Plate For Steel Tank Body
Product Introduction:
Double-sided stainless steel, which is a new generation of green environmental protection composite material with complete intellectual property rights and advanced level in the world. It has 9 patents such as "stainless steel and carbon steel three-layer metal composite plate". It took the lead in compiling the Fujian Provincial engineering construction local standard "Application Technical Standard of Double-sided Stainless Steel Composite Steel Pipe for Water Supply and Drainage Engineering" (DBJ/T 13-394-2021). In cooperation with the Science and Technology and Industrialization Development Center of the Ministry of Housing and Urban-Rural Development, we have compiled three Green Building Materials Evaluation Standards, including double-sided stainless steel composite material, double-sided stainless steel composite steel plate, double-sided stainless steel composite steel pipe and pipe fittings. At present, we have developed 13 kinds of "green tube" products, under the same working condition and mechanical index requirements, can reduce more than 50% of the steel, more than 85% of the stainless steel consumption, known as "green steel". "Green steel" is a new basic industrial material with a huge market volume. It is widely used in civil water supply and drainage, military aviation fuel supply and other projects. It has remarkable economic, social and ecological benefits, and has been praised by all parties.
Experimental data of double-sided stainless steel composites
| Name | Thickness (mm) |
Reference national standard |
Yield strength Rp0.2/MPa |
Tensile strength Rm/MPa |
Elongation A/% |
|
Composite plate |
6-8 |
Actual data |
475-573 | 660-713 | 23.0 |
|
304 Stainless steel |
6-8 | GB/T12771 | ≥210 | ≥520 | ≥40 |
| Q355B | ≤16 | GB/T1591 | ≥355 | 470-630 | ≥21 |
Product Specification for Large Diameter Double Sided Stainless Steel Composite Pipe
| No. | Nominal Diameter (mm) | External Diameter (mm) | Thickness (mm) | No. | Nominal Diameter (mm) | External Diameter (mm) | Thickness (mm) | |
| 1 | DN150 | DN159 | 5 | 15 | DN700 | DN720 | 5 | |
| 2 | DN200 | DN219 | 5 | 16 | DN700 | DN720 | 6 | |
| 3 | DN300 | DN325 | 5 | 17 | DN700 | DN720 | 7 | |
| 4 | DN300 | DN325 | 6 | 18 | DN800 | DN820 | 6 | |
| 5 | DN300 | DN325 | 7 | 19 | DN800 | DN820 | 8 | |
| 6 | DN400 | DN426 | 5 | 20 | DN900 | DN920 | 7 | |
| 7 | DN400 | DN426 | 6 | 21 | DN900 | DN920 | 8 | |
| 8 | DN400 | DN426 | 7 | 22 | DN1000 | DN1020 | 8 | |
| 9 | DN500 | DN530 | 5 | 23 | DN1000 | DN1020 | 10 | |
| 10 | DN500 | DN530 | 6 | 24 | DN1100 | DN1120 | 8 | |
| 11 | DN500 | DN530 | 7 | 25 | DN1100 | DN1120 | 10 | |
| 12 | DN600 | DN630 | 5 | 26 | DN1200 | DN1220 | 8 | |
| 13 | DN600 | DN630 | 6 | 27 | DN1200 | DN1220 | 11 | |
| 14 | DN600 | DN630 | 7 |
Structure
