Membrane Type Nitrogen Generator Working Principle

Under a certain pressure, using the large difference of the diffusion rate between nitrogen and oxygen from the air

in the carbon molecular sieve, a large number of oxygen is adsorpted by carbon molecular sieve, while nitrogen is

collected in a short time, to achieve separation of oxygen and nitrogen.

The adsorption capacity of carbon molecular sieve is significantly different with different oxygen

pressures, reducing the pressure will release oxygen from carbon molecular sieve, this make carbon molecular

sieve regeneration, then can be used repeatedly.

Using two adsorption towers, one for adsorption and nitrogen generator, the other for desorption and recycling.

They switch with each other, thus continuous output of high-quality nitrogen.

Nitrogen separation

At the heart of the Nitrogen Membrane separation technology are polymeric membrane materials that

allow for the rapid passage of one gas while minimizing the passage of another when applying pressure

gradient across the membrane. Membrane materials are formed into hollow fibers to provide high

surface area for high bolometric gas processing rates.

Selective Permeability

Nitrogen membranes separate gases by the principle of selective permeation across the membranes

wall.

For nitrogen polymeric membranes, the rate of permeation of each gas is determined by its solubility

in the nitrogen membrane material, and the rate of diffusion through the molecular free volume in the

nitrogen membrane wall. Gases that exhibit high solubility in the nitrogen membranes, and gases that

are small in molecular size, permeate faster than larger, less soluble gases.

Fast Gases and Slow Gases

"Fast" gases permeate through the nitrogen membrane wall more readily than "slow" gases, thus

separating the original gas mixture into two streams. The purity of the desired streams can be adjusted

by changing the operating conditions.

The ability of a nitrogen membranes to separate two gases is determined by their "selectivity", the ratio

of permeabilities of the two gases. The higher the selectivity, the more efficient the separation and less

energy is needed to run the system.

Membrane Type Nitrogen Generator Specifications:

After Sales Service Commitment

Free warranty for the equipments during the promised period

1. The nitrogen generator,1 year warranty, maintenance responding time is less than eight hours.
2. Ancillary equipment ,1 year warranty, maintance responding time is less than 8 hours.
3. Lifelong maintance service in a timely manner, the responding time is less than 8 hours.

4.Provide 24-hour hotline service.
5.Return visit every six months (callback or on the spot).

6. General failure:within 2 hours of repair
7. Serious failure:within 12 hours of repair
8. Supply accessories in a timely manner, the delivery time is generally 1-7 days.

9.Free repair at the expiry time of warranty
