Industrial Nitrogen Generation Equipment , Mobile Nitrogen Gas Generator

Industrial Nitrogen Generation Equipment , Mobile Nitrogen Gas Generator

PSA Nitrogen Generation Equipment Introduction:

N2 and O2 all have a quadrupole, for the reason that the quadrupole of N2(0.31 Å)is bigger than

the quadrupole of O2 (0.10 Å), the adsorption capacity by molecular sieve to N2 is stronger than O2.

When the compressed air in certain pressure flow through adsorption bed formed by molecular sieve,

the N2 gas is absorbed and O2 is obtained by separation.

The main part of O2 generator is two towers filled with molecular sieve , when the compressed air get

into adsorption tower, the N2, is absorbed by molecular sieve, N2 is produced from the export terminal .

When one tower produces N2, another tower release the N2 by reducing the pressure to get the

renewable desorption of carbon molecular sieve. Two towers alternate adsorption and regeneration

to output N2 continuously.

Nitrogen Generation Equipment Technical Specifications:

Capacity: 2~150 Nm3/h

Purity: 92±2%

Initial Pressure: 0.05~0.4 Mpa

Dew point: -65℃

Nitrogen Generation Equipment Features

1).Full Automation

All systems are designed for un-attended operation and automatic Oxygen demand adjustment.

2).Lower Space Requirement

The design and Instrument makes the plant size very compact,assembly on skids,prefabricated from

factory.

3).Fast Start-up

Start up time is only 5 minutes to get desired Oxygen purity.So these units can be switched ON&OFF

as per Oxygen demand changes.

4).High Reliability

Very reliable for continuous and steady operation with constant Oxygen purity.Plant availability time is

better than 99% always.

Nitrogen Generation Equipment Application :

Metallurgy / heat treatment

Pharmaceutical industry

Glass and lighting industry

Oil & Gas

Why they always choose SINCE?

Many years of experience and expertise in manufacturing and supplying gas plants;

,CCS,TS certified company for quality gas plants and best after -sale services; SINCE is the seldom

 company who got ,TS (Manufacture License of special equipment)

CCS(CHINA CLASSIFICATION SOCIETY) certificate,SINCE also can manufacture marine nitrogen

generator.

Excellent infrastructure set up teamed by experienced and qualified engineers.

Sophisticated and developed R&D wing in assistance for installation and use of plants.
