Since Gas Medical Oxygen Generator For Hospital , Oxygen Generation System

Since Gas Medical Oxygen Generator For Hospital , Oxygen Generation System

  • Since Gas Medical Oxygen Generator For Hospital , Oxygen Generation System
Since Gas Medical Oxygen Generator For Hospital , Oxygen Generation System
Product Details:
Place of Origin: Suzhou,China
Brand Name: SINCE-GAS
Certification: CE,ABS,CCS,BV,DNV,ASME,GOST,
Model Number: PO
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Normal exported wooden case
Delivery Time: 2 months after received down payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 sets/year
Contact Now
Detailed Product Description
Capacity: 5-1500 Nm3/h Purity: 92±2%
Dew Point: -65℃ Supply Power: 220V/50Hz
Operate Power: 1 KW Appliction: Hospital,Medicial Industry
High Light:

Medical Grade Oxygen Generator

,

Hospital Oxygen Generator

,

1500 Nm3/h Medical Oxygen Generator



Since Gas Medical Oxygen Generator For Hospital , Oxygen Generation System





PSA oxygen generator

PSA ( Pressure Swing Adsorption) Technology a revolution in Non Cryogenic Air Separation and

Oxygen Generation Technology uses special grade of ZMS ( Zeolite Molecular Sieve).

The compressed air is passed through a Twin Tower PSA module interconnected with automatic

changeover valves. After passing through a Refrigerated Dryer air gets dried. Dried compressed air

will now come in contact with bed of Zeolite molecular sieves (ZMS). Zeolite Molecular Sieves are special

grade of adsorbent which have the property of preferential adsorption of nitrogen molecules. At a time

one tower remains under nitrogen production cycle, whereas the other tower undergoes regeneration

which is achieved through depressurization of the tower to atmospheric pressure. The outgoing oxygen

gas is sent to a surge vessel where the minimum pressure will be maintained with the help of Back

pressure Regulator

Since Gas Medical Oxygen Generator For Hospital , Oxygen Generation System 0



Technical Specifications:

Capacity: 2~150 Nm3/h

Purity: 92±2%

Initial Pressure: 0.05~0.4 Mpa

Dew point: -65℃



Technical Features:

Fully Automatic Operation requiring no special attention- Manless Operation

Generates Oxygen as and when required – Plug It, Switch On & Forget

Easy to install and maintain – Skid Mounted & precommissioned

Purity of Oxygen up to 90-95% can be achieved

PSA (Twin Tower Pressure Swing Adsorption)Based up to 150 NM3/hr

VPSA (Three Tower)For 150 Nm3/hr to 1500 Nm3/hr

VSA (Three Tower) For capacities more than 1500 Nm3/hr



Application :



1. After the oxygen generator,  the oxygen purification system is equipped to guarantee the quality of

the O2 and removing dust, eliminating bacteria and stabilizing pressure to ensure the oxygen outputted

stably and meeting medical standards.
2. Users only need to turn the start/stop button to gain the oxygen with designing required flow capacity

and purity within 30 minutes.

3. Single line and double lines types are available for option. Users are suggested to choose the single

line type when they only require a stable flow capacity; choose double lines when demand is unstable

and sometimes meet extra peak values.



During the last 10 years,about 98% old customers firmly choose SINCE



Why they always choose SINCE?

Many years of experience and expertise in manufacturing and supplying gas plants;

,CCS,TS certified company for quality gas plants and best after -sale services; SINCE is the seldom

company who got ,TS (Manufacture License of special equipment)

CCS(CHINA CLASSIFICATION SOCIETY) certificate,SINCE also can manufacture marine nitrogen

generator.

Excellent infrastructure set up teamed by experienced and qualified engineers.

Sophisticated and developed R&D wing in assistance for installation and use of plants.
