ISO Certified PSA Nitrogen Generator 99.99% Purity Industrial

99.99% PSA Nitrogen Generator

ISO PSA Nitrogen Generator

99.99% Cryogenic Nitrogen Generator

Place of Origin:

China

Brand Name:

SINCE-GAS

Certification:

CE,ABS,CCS,BV,DNV,ASME,GOST,

Model Number:

Request A Quote

ISO Certified PSA Nitrogen Generator 99.99% Purity Industrial

Product Details

Name:

Cryogenic Nitrogen Generator

Purity:

95%-99.9995%

Type:

Membrane Type

Advantage:

Low Power Consumption

Application:

Industrial

Feature:

Powerful

Other Name:

Nitrogen Making Machine

Certification:

ISO9001

Highlight:

99.99% PSA Nitrogen Generator

ISO PSA Nitrogen Generator

99.99% Cryogenic Nitrogen Generator

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

The normal packing is wooden box, if export to Europe country.the wooden box will be fumigated. if the inner packing is too tighter, we may use PE film to wrap the machine.or according to customer's special requirements.

Delivery Time

2 months after received down payment

Payment Terms

T/T or west union,L/C

Supply Ability

1,000 sets per year

BV,,CCS,TS,ISO Oil&Gas nitrogen generator package system

Get Best Price

/CCS/BV/ISO/TS Oil refinery nitrogen generator system package

Get Best Price

BV,,CCS,ISO,TS Heat treatment nitrogen generator package system

Get Best Price

BV CCS ISO TS Electron Psa Nitrogen Gas Generator Package System

Get Best Price

Contact Now

Product Description

ISO Membrane Type 99.99% PSA Nitrogen Generator

Product Specifications

Attribute	Value
Name	Cryogenic Nitrogen Generator
Purity	95%-99.9995%
Type	Membrane Type
Advantage	Low Power Consumption
Application	Industrial
Feature	Powerful
Other Name	Nitrogen Making Machine
Certification	ISO9001

Technical Features

Working Principle: The PSA oxygen generator separates air using two adsorption towers filled with molecular sieve. Compressed air is filtered, dried, and then enters the adsorption tower where nitrogen is adsorbed by the molecular sieve while oxygen flows out and is stored in the oxygen buffer tank. The system alternates between towers automatically via computer-controlled valves.

Technical Specifications

Nitrogen Capacity	Nitrogen Purity	Nitrogen Pressure	Dew Point	Function
5~3000Nm³/h	>99.9995%	0.1~0.8MPa (adjustable)	-45~-60℃ (under normal pressure)	Producing nitrogen gas with designed flow rate, purity and outlet pressure

Key Features

Intelligent, automatic operation with remote/automatic control
Special air distribution system ensures stable operation
Nitrogen purity, pressure, and flow rate monitoring
Adjustable purity and flow rate to meet customer needs

Model Specifications

No	Model	Capacity (Nm³/h)	Purity	Power (KW)	Overall Size (mm)
1-4	PN-3-39 to PN-8-295	3-8	95%-99.9%	0.5	1800×1400×1500
5-8	PN-5-49 to PN-15-29	5-15	99%-99.99%	0.5	1800×1400×1800
9-12	PN-10-49 to PN-30-39	10-30	99%-99.99%	0.5	2000×1700×2250
13-16	PN-15-49 to PN-45-29	15-45	99%-99.99%	0.5	2100×1800×2200
17-20	PN-20-49 to PN-60-29	20-60	99%-99.99%	0.5	2200×1800×2200
21-24	PN-30-49 to PN-88-29	30-88	99%-99.99%	0.5	2400×1900×2200

Note: For more information please contact Since Gas System Co., Ltd or send us an email directly.

System Advantages

Convenient and efficient nitrogen generation with advanced technology
Compact design with low space requirements and minimal installation needs
More economical than alternative nitrogen supply methods
Fully automated operation with PLC control system
Premium components including Japan Takeda CMS, Mitsubishi PLC, and Germany Burkert valves

Technical Parameters

Resource: Air
Pressure: 5-10 bar
Pressure dew point: ≤10°C
Oil content: ≤0.003mg/m³
Product nitrogen pressure: ≤9bar
Normal pressure dew point: ≤-40°C
Purity: 95%-99.9995%
Nitrogen capacity: 5-5000Nm³/H

Customer Satisfaction: Over the last 10 years, about 98% of our customers have chosen to continue working with SINCE.
