High Effiecent Membrane Nitrogen Generator PSA Nitrogen Plant 95% - 99.99%

High Effiecent Membrane Nitrogen Generator PSA Nitrogen Plant 95% - 99.99%

  • High Effiecent Membrane Nitrogen Generator PSA Nitrogen Plant 95% - 99.99%
High Effiecent Membrane Nitrogen Generator PSA Nitrogen Plant 95% - 99.99%
Product Details:
Place of Origin: China
Brand Name: SINCE-GAS
Certification: CE,ABS,CCS,BV,DNV,ASME,GOST,
Model Number: MN
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: The normal packing is wooden box, if export to Europe country.the wooden box will be fumigated. if the inner packing is too tighter, we may use PE film to wrap the machine.or according to customer's special requirements.
Delivery Time: 2 months after received down payment
Payment Terms: T/T or west union,L/C
Supply Ability: 1,000 sets per year
Contact Now
Detailed Product Description
High Light:

Nitrogen Membrane Generators

,

Membrane Type Nitrogen Generator


High Effiecent Membrane Nitrogen Generator PSA Nitrogen Plant 95% - 99.99%


Description:

Membrane Technology
Nitrogen separation
At the heart of the Nitrogen Membrane separation technology are polymeric membrane materials that allow
for the rapid passage of one gas while minimizing the passage of another when applying pressure gradient
 across the membrane. Membrane materials are formed into hollow fibers to provide high surface area for
 high bolometric gas processing rates.


Selective Permeability

Nitrogen membranes separate gases by the principle of selective permeation across the membranes wall.

High Effiecent Membrane Nitrogen Generator PSA Nitrogen Plant 95% - 99.99% 0

For nitrogen polymeric membranes, the rate of permeation of each gas is determined by its solubility in the
nitrogen membrane material, and the rate of diffusion through the molecular free volume in the nitrogen
membrane wall. Gases that exhibit high solubility in the nitrogen membranes, and gases that are small in
molecular size, permeate faster than larger, less soluble gases.


Fast Gases and Slow Gases

"Fast" gases permeate through the nitrogen membrane wall more readily than "slow" gases, thus separating
 the original gas mixture into two streams. The purity of the desired streams can be adjusted by changing the
 operating conditions.

High Effiecent Membrane Nitrogen Generator PSA Nitrogen Plant 95% - 99.99% 1

The ability of a nitrogen membranes to separate two gases is determined by their "selectivity", the ratio of
permeabilities of the two gases. The higher the selectivity, the more efficient the separation and less energy
 is needed to run the system.


Specifications:

No

Model

Capacity(Nm3/h)

Purity

Power(KW)

Overall size(mm)

1
2
3
4

MN-3-39
MN-5-29
MN-5-295
MN-8-295

3
5
5
8

99.9%
99.5%
99%
95%



0.5



1800*1400*1500

5
6
7
8

MN-5-49
MN-8-39
MN-12-295
MN-15-29

5
8
12
15

99.99%
99.9%
99.5%
99%



0.5



1800*1400*1800

9
10
11
12

MN-10-49
MN-15-39
MN-25-295
MN-30-39

10
15
25
30

99.99%
99.9%
99.5%
99%



    0.5



2000*1700*2250

13
14
15
16

MN-15-49
MN-22-39
MN-35-295
MN-45-29

15
22
35
45

99.99%
99.9%
99.5%
99%



0.5

2100*1800*2200

17
18
19
20

MN-20-49
MN-30-39
MN-50-295
MN-60-29

20
30
50
60

99.99%
99.9%
99.5%
99%



0.5

2200*1800*2200

21
22
23
24

MN-30-49
MN-45-39
MN-75-295
MN-88-29

30
45
75
88

99.99%
99.9%
99.5%
99%



0.5

2400*1900*2200

25
26
27
28

MN-40-49
MN-60-39
MN-100-295
MN-120-29

40
60
100
120

99.99%
99.9%
99.5%
99%



0.5

2500*2100*2500

...

...

...

...

...

...

Note:More news please free to contact Since Gas System Co.,Ltd or send email to us directly



Technical parameter :

Resource: Air
Pressure:5-10 bar
Pressure dew point:≤-40℃
Oil content ≤0.003mg/m3
Air change with the Nitrogen& Oxygen

Product nitrogen
Pressure:≤10bar
Normal pressure dew point:≤-40degree
Purity:95%-99.9%
Nitrogen capacity :5-100Nm3/H
During the last 10 years,about 98% old customers firmly choose SINCE


Why they always choose SINCE?

Many years of experience and expertise in manufacturing and supplying gas plants;
,CCS,TS certified company for quality gas plants and best after -sale services; SINCE is the seldom
company who got ,TS (Manufacture License of special equipment) CCS(CHINA CLASSIFICATION SOCIETY)
 certificate,SINCE also can manufacture marine nitrogen generator.
Excellent infrastructure set up teamed by experienced and qualified engineers.
Sophisticated and developed R&D wing in assistance for installation and use of plants.
